EXC-14CH120U
RoHS
RoHS compliant
RoHS compliantPackage 0302 (0806 Metric), 4 Lead
Category Filters / Common Mode Chokes
Description
CMC 100MA 2LN 12 OHM SMD
PDF
/
Buying Options
Total Price: USD $0.2
Unit Price: USD $0.2024
≥1 USD $0.2024
≥10 USD $0.1628
≥100 USD $0.150656
≥500 USD $0.13816
≥1000 USD $0.121792
≥3000 USD $0.11799
Inventory: 1260
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height 508μm
Technical
Impedance @ Frequency 12Ohm @ 100MHz
Current Rating (Max) 100mA
DC Resistance (DCR) (Max) 1Ohm
Number of Lines 2
Filter Type Signal Line
Case Code (Imperial) 0302
Case Code (Metric) 0806
Voltage - Rated DC 5V
HTS Code 8504.50.80.00
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.033Lx0.026W 0.85mmx0.65mm
Series EXC14
Published 2014
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Package / Case 0302 (0806 Metric), 4 Lead
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 11 Weeks
