ELF-24V070A
RoHS
/
Package Vertical, 4 PC Pin
Category Filters / Common Mode Chokes
Description
COMMON MODE CHOKE 7A 2LN TH
PDF
/
Buying Options
Total Price: USD $10.26
Unit Price: USD $10.260314
≥1 USD $10.260314
≥200 USD $4.093622
≥400 USD $3.957081
≥1000 USD $3.890123
Inventory: 5439
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Length 37mm
Height 42.4942mm
Technical
DC Resistance (DCR) (Max) 16mOhm Typ
Number of Lines 2
Filter Type SINGLE PHASE EMI FILTER
Current 7A
Inductance 800 μH
Reach Compliance Code unknown
Additional Feature INDUCTANCE 0.8 MILLI HENRY
Min Operating Temperature -20°C
Max Operating Temperature 105°C
Terminal Finish Tin/Copper (Sn/Cu)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e2
Size / Dimension 1.457Lx0.945W 37.00mmx24.00mm
Series V
Published 2006
Packaging Bulk
Physical
Package / Case Vertical, 4 PC Pin
Mounting Type Through Hole
Mount Through Hole
