ELF-24V030A
RoHS
/
Package Vertical, 4 PC Pin
Category Filters / Common Mode Chokes
Description
COMMON MODE CHOKE 3A 2LN TH
PDF
/
Inventory: 1374
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Vertical, 4 PC Pin
Technical
Packaging Bulk
Published 2006
Series V
Size / Dimension 1.457Lx0.945W 37.00mmx24.00mm
JESD-609 Code e2
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Terminal Finish Tin/Copper (Sn/Cu)
Max Operating Temperature 105°C
Min Operating Temperature -20°C
Reach Compliance Code unknown
Inductance 8.2 mH
Current 3A
Filter Type SINGLE PHASE EMI FILTER
Number of Lines 2
DC Resistance (DCR) (Max) 90mOhm Typ
Dimensions
Height 42.4942mm
Length 37mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
