ELF-23F022A
RoHS
/
Package Vertical, 4 PC Pin
Category Filters / Common Mode Chokes
Description
COMMON MODE CHOKE 2.2A 2LN TH
PDF
/
Inventory: 6983
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Vertical, 4 PC Pin
Technical
Packaging Bulk
Published 2006
Series F
Size / Dimension 0.945Lx0.906W 24.00mmx23.00mm
JESD-609 Code e2
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Terminal Finish Tin/Copper (Sn/Cu)
Max Operating Temperature 115°C
Min Operating Temperature -20°C
Additional Feature INDUCTANCE 1 MILLI HENRY
Reach Compliance Code unknown
Inductance 1 mH
Current 2.2A
Number of Lines 2
DC Resistance (DCR) (Max) 97mOhm Typ
Dimensions
Height 13.9954mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
