ELF-21N016A
RoHS
/
Package Vertical, 4 PC Pin
Category Filters / Common Mode Chokes
Description
Common Mode Chokes Dual 15mH 1.6A 212mOhm DCR Thru-Hole
PDF
/
Buying Options
Total Price: USD $2.84
Unit Price: USD $2.839803
≥1 USD $2.839803
≥200 USD $1.133033
≥500 USD $1.094959
≥1000 USD $1.076578
Inventory: 6573
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Height 29.9974mm
Technical
DC Resistance (DCR) (Max) 212mOhm Typ
Number of Lines 2
DC Current 1.6A
Max DC Current 1.6A
Current 1.6A
Element Configuration Dual
Inductance 15 mH
Voltage - Rated AC 250V
Depth 21mm
Min Operating Temperature -20°C
Max Operating Temperature 115°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e2
Size / Dimension 0.787Lx1.260W 20.00mmx32.00mm
Series N
Published 2006
Packaging Bulk
Physical
Package / Case Vertical, 4 PC Pin
Mounting Type Through Hole
Mount Through Hole
