Package Vertical, 4 PC Pin
Category Filters / Common Mode Chokes
Description Common Mode Chokes Dual 4.7mH 2.7A Thru-Hole
PDF
/
Inventory: 9408
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mount Through Hole
Mounting Type Through Hole
Package / Case Vertical, 4 PC Pin

Technical

Packaging Bulk
Published 2006
Series N
Size / Dimension 0.787Lx1.260W 20.00mmx32.00mm
JESD-609 Code e2
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 115°C
Min Operating Temperature -20°C
Depth 21mm
Voltage - Rated AC 250V
Inductance 4.7 mH
Element Configuration Dual
Current 2.7A
Max DC Current 2.7A
Number of Lines 2
DC Resistance (DCR) (Max) 82mOhm Typ

Dimensions

Height 29.9974mm

Compliance

RoHS Status Non-RoHS Compliant
Lead Free Lead Free
