ELF-20N008A image
Favorite
ELF-20N008A image
Favorite
RoHS
/
Package Vertical, 4 PC Pin
Category Filters / Common Mode Chokes
Description Common Mode Chokes Dual 43mH 800mA Thru-Hole
PDF
/
Inventory: 8246
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status Non-RoHS Compliant

Dimensions

Height 29.9974mm

Technical

DC Resistance (DCR) (Max) 770mOhm Typ
Number of Lines 2
Max DC Current 800mA
Current 800mA
Element Configuration Dual
Inductance 43 mH
Voltage - Rated AC 250V
Depth 21mm
Min Operating Temperature -20°C
Max Operating Temperature 115°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e2
Size / Dimension 0.787Lx1.260W 20.00mmx32.00mm
Series N
Published 2006
Packaging Bulk

Physical

Package / Case Vertical, 4 PC Pin
Mounting Type Through Hole
Mount Through Hole
