ELF-20N006A
RoHS
/
Package Vertical, 4 PC Pin
Category Filters / Common Mode Chokes
Description
Common Mode Chokes Dual 69mH 600mA Thru-Hole
PDF
/
Inventory: 8086
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Vertical, 4 PC Pin
Technical
Packaging Bulk
Published 2006
Series N
Size / Dimension 0.787Lx1.260W 20.00mmx32.00mm
JESD-609 Code e2
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 115°C
Min Operating Temperature -20°C
Depth 21mm
Voltage - Rated AC 250V
Inductance 69 mH
Element Configuration Dual
Current 600mA
Max DC Current 600mA
Number of Lines 2
DC Resistance (DCR) (Max) 1.25Ohm Typ
Dimensions
Height 29.9974mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
Alternative Model
