ELF-18D620
RoHS
/
Package Vertical, 4 PC Pin
Category Filters / Common Mode Chokes
Description
CMC 100MH 400MA 2LN TH
PDF
/
Inventory: 7382
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Vertical, 4 PC Pin
Technical
Operating Temperature -20°C~105°C
Packaging Bulk
Published 2002
Series H
Size / Dimension 1.122Lx1.142W 28.50mmx29.00mm
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 105°C
Min Operating Temperature -20°C
Voltage - Rated AC 250V
Inductance 100 mH
Current 400mA
Number of Lines 2
DC Resistance (DCR) (Max) 2.448Ohm Typ
Current Rating (Max) 400mA
Inductance @ Frequency 100mH @ 1kHz
Dimensions
Height 23.495mm
Length 28.4988mm
Width 29.0068mm
Height (Max) 0.925 23.50mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Lead Free
