ELF-18D617F
RoHS
/
Package Vertical, 4 PC Pin
Category Filters / Common Mode Chokes
Description
CMC 2.2MH 2.8A 2LN TH
PDF
/
Buying Options
Total Price: USD $4.67
Unit Price: USD $4.666047
≥1 USD $4.666047
≥200 USD $1.861692
≥400 USD $1.799986
≥1000 USD $1.769789
Inventory: 1785
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Vertical, 4 PC Pin
Technical
Operating Temperature -20°C~105°C
Packaging Bulk
Published 2002
Series H
Size / Dimension 1.122Lx1.142W 28.50mmx29.00mm
JESD-609 Code e2
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Terminal Finish Tin/Copper (Sn/Cu)
Voltage - Rated AC 250V
Inductance 2.2 mH
Current 2.8A
Number of Lines 2
DC Resistance (DCR) (Max) 58mOhm Typ
Inductance @ Frequency 2.2mH @ 1kHz
Dimensions
Height 23.495mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
Alternative Model
