ELF-18D433 image
Favorite
ELF-18D433 image
Favorite
RoHS
/
Package Vertical, 4 PC Pin
Category Filters / Common Mode Chokes
Description CMC 3.9MH 1.5A 2LN TH
PDF
/
Inventory: 9182
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mount Through Hole
Mounting Type Through Hole
Package / Case Vertical, 4 PC Pin

Technical

Operating Temperature -20°C~105°C
Packaging Bulk
Published 2002
Series H
Size / Dimension 0.945Lx0.984W 24.00mmx25.00mm
JESD-609 Code e2
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Inductance @ Frequency 3.9mH @ 1kHz
DC Resistance (DCR) (Max) 176mOhm Typ
Number of Lines 2
Current 1.5A
Inductance 3.9 mH
Voltage - Rated AC 250V
Reach Compliance Code unknown
Terminal Finish Tin/Copper (Sn/Cu)

Compliance

Lead Free Contains Lead
RoHS Status Non-RoHS Compliant

Dimensions

Height 20.4978mm
