ELF-18D424F
RoHS
/
Package Vertical, 4 PC Pin
Category Filters / Common Mode Chokes
Description
CMC 5.6MH 1.4A 2LN TH
PDF
/
Inventory: 8676
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height 20.4978mm
Technical
Inductance @ Frequency 5.6mH @ 1kHz
DC Resistance (DCR) (Max) 191mOhm Typ
Number of Lines 2
Current 1.4A
Inductance 5.6 mH
Voltage - Rated AC 250V
Reach Compliance Code unknown
Terminal Finish Tin/Copper (Sn/Cu)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e2
Size / Dimension 0.945Lx0.984W 24.00mmx25.00mm
Series H
Published 2002
Packaging Bulk
Operating Temperature -20°C~105°C
Physical
Package / Case Vertical, 4 PC Pin
Mounting Type Through Hole
Mount Through Hole
