ELF-18D422 image
Favorite
ELF-18D422 image
Favorite
RoHS
/
Package Vertical, 4 PC Pin
Category Filters / Common Mode Chokes
Description CMC 22MH 600MA 2LN TH
PDF
/
Inventory: 3593
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Contains Lead
RoHS Status Non-RoHS Compliant

Dimensions

Height (Max) 0.807 20.50mm
Width 24.9936mm
Length 24.003mm
Height 20.4978mm

Technical

Inductance @ Frequency 22mH @ 1kHz
Current Rating (Max) 600mA
DC Resistance (DCR) (Max) 987mOhm Typ
Number of Lines 2
Current 600mA
Inductance 22 mH
Voltage - Rated AC 250V
Min Operating Temperature -20°C
Max Operating Temperature 105°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Size / Dimension 0.945Lx0.984W 24.00mmx25.00mm
Series H
Published 2002
Packaging Bulk
Operating Temperature -20°C~105°C

Physical

Package / Case Vertical, 4 PC Pin
Mounting Type Through Hole
Mount Through Hole
