ELF-18D412
RoHS
/
Package Vertical, 4 PC Pin
Category Filters / Common Mode Chokes
Description
CMC 6.8MH 1.2A 2LN TH
PDF
/
Inventory: 4751
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Vertical, 4 PC Pin
Technical
Operating Temperature -20°C~105°C
Packaging Bulk
Published 2002
Series H
Size / Dimension 0.945Lx0.984W 24.00mmx25.00mm
JESD-609 Code e2
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Terminal Finish Tin/Copper (Sn/Cu)
Reach Compliance Code unknown
Voltage - Rated AC 250V
Inductance 6.8 mH
Current 1.2A
Number of Lines 2
DC Resistance (DCR) (Max) 290mOhm Typ
Inductance @ Frequency 6.8mH @ 1kHz
Dimensions
Height 20.4978mm
Compliance
RoHS Status RoHS Compliant
Lead Free Contains Lead
