51504C
RoHS
RoHS compliant
RoHS compliantPackage Vertical, 4 PC Pin
Category Filters / Common Mode Chokes
Description
MURATA POWER SOLUTIONS 51504C CHOKE, 0.5MH, 4.1A
PDF
/
Buying Options
Total Price: USD $28.19
Unit Price: USD $28.1922
≥1 USD $28.1922
≥10 USD $23.1325
≥100 USD $22.40955
≥500 USD $21.6866
≥1000 USD $20.96365
Inventory: 3979
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Length 18mm
Height 24mm
Technical
DC Resistance (DCR) (Max) 27mOhm
Number of Lines 2
DC Current 4.1A
Filter Type Power Line
Lead/Base Style Pin
Max DC Current 4.1A
Inductance 500 μH
Lead Pitch 12.7mm
Approval Agency UL
Military Standard Not
Depth 10mm
Number of Functions 2
Shielding Unshielded
ECCN Code EAR99
Termination Radial
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Size / Dimension 0.709Lx0.394W 18.00mmx10.00mm
Series 5100
Packaging Tray
Operating Temperature -40°C~125°C
Physical
Number of Pins 4
Package / Case Vertical, 4 PC Pin
Mounting Type Through Hole
Mount Radial, Through Hole
Contact Plating Tin
Supply Chain
Factory Lead Time 12 Weeks
