PLY10AS9720R6D2B
RoHS
/
Package Vertical, 4 PC Pin
Category Filters / Common Mode Chokes
Description
Common Mode Filters / Chokes 9.7mH 0.6A 300volt
PDF
/
Inventory: 6398
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 16mm
Length 18mm
Height 17.5006mm
Technical
Rated Voltage 300V
DC Resistance (DCR) (Max) 2Ohm
Number of Lines 2
Filter Type Power Line
Max DC Current 600mA
Current 600mA
Inductance 9.7 mH
Physical Dimension L18.0XB16.0XH17.5 (mm)/L0.709XB0.63XH0.689 (inch)
Voltage - Rated AC 300V
Packing Method BOX
Terminal Finish Tin/Copper (Sn/Cu)
Termination Radial
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e2
Size / Dimension 0.709Lx0.630W 18.00mmx16.00mm
Series PLY10
Packaging Bulk
Operating Temperature -25°C~60°C
Physical
Package / Case Vertical, 4 PC Pin
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Lifecycle Status DISCONTINUED (Last Updated: 4 weeks ago)
