PLH10AN3711R0P2B
RoHS
/
Package Vertical, 4 PC Pin
Category Filters / Common Mode Chokes
Description
PLH10 Vertical 4PC Pin Tin/Copper (Sn/Cu) 2 Common Mode Choke 1A 100MOhm 18mm 370muH
PDF
/
Inventory: 1904
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Lifecycle Status DISCONTINUED (Last Updated: 1 month ago)
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Vertical, 4 PC Pin
Technical
Operating Temperature -25°C~60°C
Packaging Bulk
Series PLH10
Size / Dimension 0.709Lx0.630W 18.00mmx16.00mm
JESD-609 Code e2
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Radial
Terminal Finish Tin/Copper (Sn/Cu)
Additional Feature INDUCTANCE 370 MICRO HENRY; HIGH-FREQUENCY TYPE; CORE VERTICAL TYPE STRUCTURE; ALIGNED WINDING TYPE
Voltage - Rated DC 300V
Packing Method BOX
Shielding Unshielded
Depth 16mm
Physical Dimension L18.0XB16.0XH17.5 (mm)/L0.709XB0.63XH0.689 (inch)
Inductance 370 μH
Current 1A
Max DC Current 1A
Lead/Base Style Pin
Filter Type Power Line
DC Current 1A
Number of Lines 2
Rated Voltage 300V
Insulation Resistance-Min 100MOhm
Dimensions
Height 17.5mm
Length 18mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
