PLA10AS7420R8R2B

Murata Electronics
RoHS
/
Package Vertical, 4 PC Pin
Category Filters / Common Mode Chokes
Description Common Mode Chokes Dual 7.4mH 800mA Thru-Hole Box
PDF
/
Inventory: 3007
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

Length 18mm
Height 17.5mm

Technical

Insulation Resistance-Min 100MOhm
DC Resistance (DCR) (Max) 640mOhm
Number of Lines 2
DC Current 800mA
Filter Type Power Line
Lead/Base Style Pin
Max DC Current 800mA
Current 800mA
Inductance 7.4 mH
Operating Frequency 50Hz Hz
Physical Dimension L18.0XB16.0XH17.5 (mm)/L0.709XB0.63XH0.689 (inch)
Approval Agency EN
Military Standard Not
Depth 16mm
Packing Method BOX
Voltage - Rated DC 250V
Additional Feature INDUCTANCE 7.4 MILLI HENRY; CORE VERTICAL TYPE STRUCTURE
Terminal Finish Tin/Copper (Sn/Cu)
Termination Radial
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e2
Size / Dimension 0.709Lx0.630W 18.00mmx16.00mm
Series PLA10
Packaging Bulk
Operating Temperature -25°C~60°C

Physical

Package / Case Vertical, 4 PC Pin
Mounting Type Through Hole
Mount Through Hole

Supply Chain

Lifecycle Status DISCONTINUED (Last Updated: 1 month ago)
