DLW5BSN351SQ2L
RoHS
/
Package Horizontal, 4 PC Pad
Category Filters / Common Mode Chokes
Description
MURATA - DLW5BSN351SQ2L - COMMON MODE CHOKE, 350 OHM, SURFACE MOUNT-SMD
PDF
/
Buying Options
Total Price: USD $8.06
Unit Price: USD $8.05505
≥1 USD $8.05505
≥10 USD $6.60915
≥100 USD $6.403
≥500 USD $6.1959
≥1000 USD $5.98975
Inventory: 6598
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Horizontal, 4 PC Pad
Number of Pins 4
Weight 299.994654mg
Core Material Ferrite
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Series DLW5B
Size / Dimension 0.197Lx0.197W 5.00mmx5.00mm
Tolerance 25%
JESD-609 Code e2
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
ECCN Code EAR99
Resistance 40mOhm
Terminal Finish Tin/Copper (Sn/Cu)
Additional Feature MAGNETICALLY SHIELDED ONE CIRCUIT TYPE
Voltage - Rated DC 125V
Packing Method TR
Shielding Unshielded
Number of Functions 2
Depth 5.3mm
Current Rating 2A
Frequency 100MHz
Military Standard Not
Voltage - Rated AC 125V
Case Code (Imperial) 2020
Insulation Resistance 10MOhm
Test Frequency 100MHz
Impedance 350 Ω
Current 2A
Max DC Current 2A
Filter Type Power, Signal Line
DC Current 2A
Number of Lines 2
DC Resistance (DCR) (Max) 40mOhm
Self Resonant Frequency 100MHz
Impedance @ Frequency 350 Ω @ 100MHz
Rated Voltage 50V
Dimensions
Height 4.5mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Lead Free
