DLP11SA670HL2L
RoHS
RoHS compliant
RoHS compliantPackage 0504 (1210 Metric), 4 Lead
Category Filters / Common Mode Chokes
Description
Common Mode Chokes Dual 67Ohm 100MHz 150mA SMD Embossed T/R
PDF
/
Buying Options
Total Price: USD $1.96
Unit Price: USD $1.9551
≥1 USD $1.9551
≥10 USD $1.60455
≥100 USD $1.5542
≥500 USD $1.50385
≥1000 USD $1.45445
Inventory: 1231
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height 914.4μm
Technical
Rated Voltage 5V
Impedance @ Frequency 67Ohm @ 100MHz
DC Resistance (DCR) (Max) 1.5Ohm
Number of Lines 2
DC Current 150mA
Filter Type Signal Line
Max DC Current 150mA
Current 150mA
Impedance 67Ohm
Test Frequency 100MHz
Case Code (Imperial) 0504
Case Code (Metric) 1210
Depth 1.1mm
Number of Functions 2
Packing Method TAPE AND REEL
Voltage - Rated DC 5V
HTS Code 8504.50.80.00
Terminal Finish Tin (Sn)
Resistance 67Ohm
ECCN Code EAR99
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Tolerance 20%
Size / Dimension 0.049Lx0.039W 1.25mmx1.00mm
Series DLP11
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Package / Case 0504 (1210 Metric), 4 Lead
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status IN PRODUCTION (Last Updated: 1 month ago)
Factory Lead Time 6 Weeks
