DLP11RB150UL2L
RoHS
RoHS compliant
RoHS compliantPackage 0504 (1210 Metric), 4 Lead
Category Filters / Common Mode Chokes
Description
MURATA DLP11RB150UL2L CHOKE, COMMON FILM , 15OHM, +/-5OHM
PDF
/
Buying Options
Total Price: USD $0.18
Unit Price: USD $0.175351
≥1 USD $0.175351
≥200 USD $0.067864
≥500 USD $0.065474
≥1000 USD $0.064306
Inventory: 1169
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Lifecycle Status IN PRODUCTION (Last Updated: 1 month ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 0504 (1210 Metric), 4 Lead
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Series DLP11
Size / Dimension 0.049Lx0.039W 1.25mmx1.00mm
Tolerance 25%
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination SMD/SMT
ECCN Code EAR99
Resistance 15Ohm
Terminal Finish TIN
HTS Code 8504.50.80.00
Voltage - Rated DC 5V
Packing Method TAPE AND REEL
Shielding Unshielded
Number of Functions 2
Current Rating 100mA
Case Code (Metric) 1210
Case Code (Imperial) 0504
Insulation Resistance 100MOhm
Test Frequency 100MHz
Impedance 15Ohm
Current 100mA
Max DC Current 100mA
Filter Type Signal Line
Number of Lines 2
DC Resistance (DCR) (Max) 1Ohm
Impedance @ Frequency 15Ohm @ 100MHz
Rated Voltage 5V
Dimensions
Height 609.6μm
Width 1mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
