DLP0QSA150HL2D
RoHS
RoHS compliant
RoHS compliantPackage 0202 (0505 Metric), 4 PC Pad
Category Filters / Common Mode Chokes
Description
CMC 100MA 2LN 15 OHM SMD
PDF
/
Buying Options
Total Price: USD $0.54
Unit Price: USD $0.5377
≥1 USD $0.5377
≥10 USD $0.4408
≥100 USD $0.4275
≥500 USD $0.41325
≥1000 USD $0.39995
Inventory: 1357
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 0.5mm
Length 0.65mm
Height 300μm
Technical
Rated Voltage 5V
Impedance @ Frequency 15Ohm @ 100MHz
DC Resistance (DCR) (Max) 1Ohm
Number of Lines 2
Rated Current 0.1A
Filter Type Signal Line
Max DC Current 100mA
Impedance 15Ohm
Test Frequency 100MHz
Case Code (Imperial) 5025
Number of Functions 2
Shielding Unshielded
Packing Method TR, 7 INCH
Voltage - Rated DC 5V
HTS Code 8504.50.80.00
Resistance 15Ohm
ECCN Code EAR99
Termination SMD/SMT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Tolerance 25%
Size / Dimension 0.026Lx0.020W 0.65mmx0.50mm
Series DLP0Q
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Package / Case 0202 (0505 Metric), 4 PC Pad
Mounting Type Surface Mount
Supply Chain
Lifecycle Status IN PRODUCTION (Last Updated: 3 weeks ago)
Factory Lead Time 8 Weeks
