SSR21NVS-07290
RoHS
RoHS compliant
RoHS compliantPackage Vertical, 4 PC Pin
Category Filters / Common Mode Chokes
Description
CMC 29.0MH 0.7A 0.53OHM WIDE IMP
PDF
/
Buying Options
Total Price: USD $2.42
Unit Price: USD $2.42
≥1 USD $2.42
≥10 USD $1.412787
≥100 USD $1.210942
≥500 USD $1.130219
Inventory: 363
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height (Max) 1.063 27.00mm
Width 16mm
Technical
Insulation Resistance-Min 100MOhm
Inductance @ Frequency 29mH @ 10kHz
Current Rating (Max) 700mA
DC Resistance (DCR) (Max) 530mOhm
Number of Lines 2
Rated Current 0.7A
Filter Type SINGLE PHASE EMI FILTER
Approval Agency UL
Voltage - Rated AC 250V
Packing Method TRAY
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Size / Dimension 0.866Lx0.630W 22.00mmx16.00mm
Series SSR
Packaging Bulk
Operating Temperature -25°C~120°C
Physical
Package / Case Vertical, 4 PC Pin
Mounting Type Through Hole
Supply Chain
Factory Lead Time 27 Weeks
