SSR21NV-10250
RoHS
RoHS compliant
RoHS compliantPackage Vertical, 4 PC Pin
Category Filters / Common Mode Chokes
Description
CMC 25.0MH 1.0A 0.36OHM HIGH IMP
PDF
/
Buying Options
Total Price: USD $2.45
Unit Price: USD $2.4464
≥1 USD $2.4464
≥10 USD $1.428337
≥100 USD $1.224274
≥500 USD $1.142662
Inventory: 309
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 27 Weeks
Physical
Mounting Type Through Hole
Package / Case Vertical, 4 PC Pin
Technical
Operating Temperature -25°C~120°C
Packaging Bulk
Series SSR
Size / Dimension 0.866Lx0.630W 22.00mmx16.00mm
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Packing Method TRAY
Voltage - Rated AC 250V
Approval Agency UL
Filter Type SINGLE PHASE EMI FILTER
Rated Current 1A
Number of Lines 2
DC Resistance (DCR) (Max) 360mOhm
Current Rating (Max) 1A
Inductance @ Frequency 25mH @ 10kHz
Insulation Resistance-Min 100MOhm
Dimensions
Width 16mm
Height (Max) 1.063 27.00mm
Compliance
RoHS Status ROHS3 Compliant
