SSR21NHS-M12220
RoHS
RoHS compliant
RoHS compliantPackage Vertical, 4 PC Pin
Category Filters / Common Mode Chokes
Description
CMC 22.0MH 1.2A 0.35OHM WIDE IMP
PDF
/
Buying Options
Total Price: USD $2.46
Unit Price: USD $2.4552
≥1 USD $2.4552
≥10 USD $2.08296
≥100 USD $1.919808
Inventory: 61
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 27 Weeks
Physical
Mounting Type Through Hole
Package / Case Vertical, 4 PC Pin
Technical
Operating Temperature -25°C~120°C
Packaging Bulk
Series SSR
Size / Dimension 0.906Lx0.906W 23.00mmx23.00mm
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Packing Method TRAY
Voltage - Rated AC 250V
Approval Agency UL
Filter Type SINGLE PHASE EMI FILTER
Number of Lines 2
DC Resistance (DCR) (Max) 350mOhm
Current Rating (Max) 1.2A
Inductance @ Frequency 22mH @ 10kHz
Insulation Resistance-Min 100MOhm
Dimensions
Height (Max) 0.571 14.50mm
Compliance
RoHS Status ROHS3 Compliant
