SSR21NH-13140
RoHS
RoHS compliant
RoHS compliantPackage Vertical, 4 PC Pin
Category Filters / Common Mode Chokes
Description
CMC 14.0MH 1.3A 0.21OHM HIGH IMP
PDF
/
Buying Options
Total Price: USD $3.62
Unit Price: USD $3.615727
≥1 USD $3.615727
≥200 USD $1.442877
≥420 USD $1.395613
≥840 USD $1.370668
Inventory: 8103
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 27 Weeks
Physical
Mounting Type Through Hole
Package / Case Vertical, 4 PC Pin
Technical
Operating Temperature -25°C~120°C
Packaging Bulk
Series SSR
Size / Dimension 0.906Lx0.906W 23.00mmx23.00mm
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Packing Method TRAY
Voltage - Rated AC 250V
Approval Agency UL
Filter Type SINGLE PHASE EMI FILTER
Rated Current 1.3A
Number of Lines 2
DC Resistance (DCR) (Max) 210mOhm
Current Rating (Max) 1.3A
Inductance @ Frequency 14mH @ 10kHz
Insulation Resistance-Min 100MOhm
Dimensions
Height (Max) 0.571 14.50mm
Compliance
RoHS Status ROHS3 Compliant
