SSHB21H-30024
RoHS
RoHS compliant
RoHS compliantPackage Vertical, 4 PC Pin
Category Filters / Common Mode Chokes
Description
CMC 2.4MH 3A 2LN TH
PDF
/
Buying Options
Total Price: USD $2.65
Unit Price: USD $2.6488
≥1 USD $2.6488
≥10 USD $2.14544
≥100 USD $1.734656
≥500 USD $1.62521
≥1000 USD $1.55217
≥3000 USD $1.50656
Inventory: 168
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height (Max) 0.610 15.50mm
Technical
Inductance @ Frequency 2.4mH @ 10kHz
Current Rating (Max) 3A
DC Resistance (DCR) (Max) 80mOhm
Number of Lines 2
Inductance 2.4 mH
Voltage - Rated AC 250V
Resistance 80mOhm
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Size / Dimension 1.024Lx0.906W 26.00mmx23.00mm
Series SSHB21H
Packaging Bulk
Operating Temperature -25°C~120°C
Physical
Package / Case Vertical, 4 PC Pin
Mounting Type Through Hole
Supply Chain
Factory Lead Time 23 Weeks
