SSHB10HS-R10122
RoHS
RoHS compliant
RoHS compliantPackage Vertical, 4 PC Pin
Category Filters / Common Mode Chokes
Description
CMC 12.2MH 1A 2LN TH
PDF
/
Buying Options
Total Price: USD $1.84
Unit Price: USD $1.8392
≥1 USD $1.8392
≥10 USD $1.16673
≥100 USD $1.13601
≥500 USD $0.970235
≥1000 USD $0.890402
≥3000 USD $0.859698
Inventory: 133
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 23 Weeks
Physical
Mounting Type Through Hole
Package / Case Vertical, 4 PC Pin
Technical
Operating Temperature -25°C~120°C
Packaging Bulk
Series SSHB10HS
Size / Dimension 0.866Lx0.669W 22.00mmx17.00mm
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Resistance 170mOhm
Voltage - Rated AC 250V
Inductance 12.2 mH
Number of Lines 2
DC Resistance (DCR) (Max) 430mOhm
Current Rating (Max) 1A
Inductance @ Frequency 12.2mH @ 10kHz
Dimensions
Height (Max) 0.610 15.50mm
Compliance
RoHS Status ROHS3 Compliant
