SS35V-40033
RoHS
RoHS compliant
RoHS compliantPackage Vertical, 6 PC Pin
Category Filters / Common Mode Chokes
Description
Common Mode Filters / Chokes 4amp 3.3mH
PDF
/
Buying Options
Total Price: USD $2.24
Unit Price: USD $2.244
≥1 USD $2.244
≥10 USD $1.8172
≥100 USD $1.46901
≥500 USD $1.37632
≥1000 USD $1.36121
Inventory: 44
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height (Max) 1.614 41.00mm
Length 37mm
Technical
Insulation Resistance-Min 100MOhm
Inductance @ Frequency 3.3mH @ 1kHz
Current Rating (Max) 4A
DC Resistance (DCR) (Max) 80mOhm
Number of Lines 2
Rated Current 4A
Filter Type Power Line
Inductance 3.3 mH
Voltage - Rated AC 250V
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 1.457Lx1.043W 37.00mmx26.50mm
Series SS
Published 2004
Packaging Bulk
Operating Temperature -25°C~120°C
Physical
Package / Case Vertical, 6 PC Pin
Mounting Type Through Hole
Supply Chain
Factory Lead Time 25 Weeks
