SH-302
RoHS
RoHS compliant
RoHS compliantPackage Vertical, 4 PC Pin
Category Filters / Common Mode Chokes
Description
CMC TROID, NI-ZN, 7.5UH, TH UL94
PDF
/
Buying Options
Total Price: USD $2.45
Unit Price: USD $2.4464
≥1 USD $2.4464
≥10 USD $2.04424
≥100 USD $1.37764
≥500 USD $1.28876
≥1000 USD $1.182104
Inventory: 2355
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 25 Weeks
Physical
Mounting Type Through Hole
Package / Case Vertical, 4 PC Pin
Technical
Operating Temperature -25°C~80°C
Packaging Bulk
Series SH
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Voltage - Rated DC 150V
Inductance 7.5 μH
Filter Type Power Line
Number of Lines 2
DC Resistance (DCR) (Max) 26mOhm
Current Rating (Max) 3A
Dimensions
Height (Max) 0.472 12.00mm
Compliance
RoHS Status ROHS3 Compliant
