SC-10-20J
RoHS
RoHS compliant
RoHS compliantPackage Vertical, 4 PC Pin
Category Filters / Common Mode Chokes
Description
Common Mode Filters / Chokes 10amp 2mH
PDF
/
Buying Options
Total Price: USD $9.23
Unit Price: USD $9.2312
≥1 USD $9.2312
≥10 USD $7.07168
≥100 USD $5.59812
≥500 USD $5.401686
Inventory: 804
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height (Max) 1.732 44.00mm
Technical
Inductance @ Frequency 2mH @ 100kHz
Current Rating (Max) 10A
DC Resistance (DCR) (Max) 22mOhm
Number of Lines 2
Rated Current 10A
Filter Type Power Line
Inductance 2 mH
Approval Agency UL
Packing Method TRAY
Voltage - Rated DC 250V
Resistance 22mOhm
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Size / Dimension 1.654Lx1.142W 42.00mmx29.00mm
Series SC
Published 2004
Packaging Bulk
Operating Temperature -25°C~105°C
Physical
Package / Case Vertical, 4 PC Pin
Mounting Type Through Hole
Supply Chain
Factory Lead Time 27 Weeks
