SC-05-30J

KEMET
RoHS
RoHS RoHS compliant
Package Vertical, 4 PC Pin
Category Filters / Common Mode Chokes
Description Common Mode Chokes Dual 3000uH 5A 0.07Ohm DCR Thru-Hole
PDF
/
Buying Options
Total Price: USD $4.66
Unit Price: USD $4.664
≥1 USD $4.664
≥10 USD $3.5464
≥100 USD $2.986368
≥500 USD $2.706396
Inventory: 265
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Height (Max) 1.299 33.00mm
Length 34mm

Technical

Inductance @ Frequency 3mH @ 100kHz
Current Rating (Max) 5A
DC Resistance (DCR) (Max) 70mOhm
Number of Lines 2
Rated Current 5A
Filter Type Power Line
Inductance 3 mH
Approval Agency UL
Packing Method TRAY
Voltage - Rated DC 250V
Resistance 70mOhm
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Size / Dimension 1.339Lx0.906W 34.00mmx23.00mm
Series SC
Published 2013
Packaging Bulk
Operating Temperature -25°C~120°C

Physical

Package / Case Vertical, 4 PC Pin
Mounting Type Through Hole

Supply Chain

Factory Lead Time 27 Weeks
