B82796C105N265
RoHS
/
Package /
Category Filters / Common Mode Chokes
Description
Tape & Reel (TR) 2 Ferrite RoHS Compliant Common Mode Choke 700mA 160mOhm 100kHz 7.5mm
PDF
/
Inventory: 1891
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 5.6896mm
Length 7.5mm
Height 4.9022mm
Technical
Current Rating (Max) 700mA
Number of Lines 2
DC Current 700mA
DC Resistance (DCR) - Parallel 160mOhm
Lead/Base Style Pin
Max DC Current 700mA
Test Frequency 100kHz
Inductance 1 mH
Voltage - Rated AC 42V
Military Standard Not
Depth 5.7mm
Voltage - Rated DC 80V
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Tolerance 50%
Packaging Tape & Reel (TR)
Physical
Material - Core Ferrite
Mount Through Hole
Contact Plating Tin
