B82793C2474N215

EPCOS
RoHS
/
Package /
Category Filters / Common Mode Chokes
Description Tape & Reel (TR) Tin (Sn) 4 DATA LINE FILTER Common Mode Choke 100mA 350mOhm 100kHz 10mm
PDF
/
Inventory: 7361
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status RoHS Compliant
REACH SVHC No SVHC

Dimensions

Width 7.1mm
Length 10mm
Height 4.8mm

Technical

Output Impedance 50Ohm Ω
Current Rating (Max) 100mA
Number of Lines 4
DC Current 100mA
DC Resistance (DCR) - Parallel 350mOhm
Rated Current 0.1A
Filter Type DATA LINE FILTER
Max DC Current 100mA
Test Frequency 100kHz
Inductance 470 μH
Approval Agency UL; IEC
Voltage - Rated AC 42V
Military Standard Not
Depth 9mm
Number of Functions 4
Packing Method TAPE AND REEL
Voltage - Rated DC 80V
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Terminal Finish Tin (Sn)
Resistance 350mOhm
ECCN Code EAR99
Termination SMD/SMT
Pbfree Code yes
JESD-609 Code e3
Tolerance 50%
Packaging Tape & Reel (TR)

Physical

Material - Core Ferrite
Number of Pins 8
Mount Surface Mount

Supply Chain

Lifecycle Status OBSOLETE (Last Updated: 2 months ago)
