B82793C2113N201
RoHS
/
Package SMD/SMT
Category Filters / Common Mode Chokes
Description
SMD/SMT Tin (Sn) 2 DATA LINE FILTER Common Mode Choke 800mA 60mOhm 100kHz 10mm
PDF
/
Inventory: 5143
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Lifecycle Status OBSOLETE (Last Updated: 1 month ago)
Physical
Mount Surface Mount
Package / Case SMD/SMT
Number of Pins 8
Material - Core Ferrite
Technical
Packaging Tape & Reel (TR)
Tolerance 50%
JESD-609 Code e3
Pbfree Code yes
ECCN Code EAR99
Resistance 60mOhm
Terminal Finish Tin (Sn)
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Voltage - Rated DC 80V
Packing Method TAPE AND REEL
Number of Functions 4
Depth 9.4mm
Military Standard Not
Voltage - Rated AC 42V
Approval Agency UL; IEC
Inductance 11 μH
Test Frequency 100kHz
Max DC Current 200mA
Filter Type DATA LINE FILTER
DC Resistance (DCR) - Parallel 60mOhm
Inductance Tolerance -30%
DC Current 200mA
Number of Lines 2
Current Rating (Max) 800mA
Output Impedance 50Ohm Ω
Dimensions
Height 4.8mm
Length 10mm
Width 7.1mm
Compliance
REACH SVHC No SVHC
RoHS Status RoHS Compliant
