B82793C0113N201
RoHS
/
Package SMD/SMT
Category Filters / Common Mode Chokes
Description
SMD/SMT Tin (Sn) 1 TELECOM FILTER Common Mode Choke 800mA 120mOhm 100kHz 7.1mm
PDF
/
Buying Options
Total Price: USD $1.82
Unit Price: USD $1.8216
≥1 USD $1.8216
≥10 USD $1.55144
≥100 USD $1.429472
≥500 USD $1.277408
≥1000 USD $1.064536
≥3000 USD $1.034106
Inventory: 13137
Minimum: 1
-
+
Technical Details
Technical
Filter Type TELECOM FILTER
Rated Current 0.8A
DC Resistance (DCR) - Parallel 120mOhm
Inductance Tolerance 30%
DC Current 800mA
Rated Voltage 80V
Max DC Current 800mA
Test Frequency 100kHz
Inductance 11 μH
Approval Agency UL
Military Standard Not
Depth 9.4mm
Number of Functions 1
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Terminal Finish Tin (Sn)
Resistance 80mOhm
Pbfree Code yes
JESD-609 Code e3
Tolerance 30%
Packaging Tape and Reel
Dimensions
Height 4.8mm
Length 7.1mm
Width 6mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Physical
Material - Core Ferrite
Weight 249.986095mg
Number of Pins 4
Package / Case SMD/SMT
Mounting Type SURFACE MOUNT
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 1 month ago)
