B82791G2601N001
RoHS
/
Package /
Category Filters / Common Mode Chokes
Description
Box Tin (Sn) - with Nickel (Ni) barrier 2 INDUCTANCE IS MEASURED AT 0.1MILLI AMPERE Common Mode Choke 600mA 2.1Ohm 10kHz 17.5mm
PDF
/
Inventory: 3241
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Dimensions
Length 17.5mm
Technical
Special Feature INDUCTANCE IS MEASURED AT 0.1 MILLI AMPERE
DC Current 600mA
Inductance-Nom (L) 6800 μH
Rated Current-Max 0.6A
DC Resistance (DCR) - Parallel 2.1Ohm
Inductor Type GENERAL PURPOSE INDUCTOR
Terminal Placement DUAL IN-LINE
Inductor Application POWER INDUCTOR
Test Frequency 10kHz
Inductance 6.8 mH
Lead Diameter 0.6 mm
Operating Temperature (Max) 125°C
Military Standard Not
Current Rating 600mA
Construction Rectangular
Depth 17.5mm
Number of Functions 2
Shielding NO
Packing Method Bulk
Terminal Finish Tin (Sn) - with Nickel (Ni) barrier
Resistance 630mOhm
ECCN Code EAR99
Number of Terminations 4
Pbfree Code yes
JESD-609 Code e3
Tolerance 50%
Packaging Box
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Number of Pins 4
Terminal Shape WIRE
Mount Through Hole
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 1 month ago)
