B82790C0105N240
RoHS
/
Package SMD/SMT
Category Filters / Common Mode Chokes
Description
SMD/SMT Matte Tin (Sn) - with Nickel (Ni) barrier 2 DATA LINE FILTER Common Mode Choke 500mA 0.17Ohm 100kHz 6mm
PDF
/
Buying Options
Total Price: USD $2.63
Unit Price: USD $2.6312
≥1 USD $2.6312
≥10 USD $2.20176
≥100 USD $2.010272
≥500 USD $1.723216
≥1000 USD $1.5796
≥3000 USD $1.531728
Inventory: 2042
Minimum: 1
-
+
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Dimensions
Length 6mm
Technical
Output Impedance 50Ohm Ω
DC Resistance (DCR) (Max) 0.17Ohm
DC Current 500mA
Inductance Tolerance -30%
DC Resistance (DCR) - Parallel 170mOhm
Filter Type DATA LINE FILTER
Max DC Current 500mA
Test Frequency 100kHz
Inductance 1 mH
Approval Agency UL; IEC
Voltage - Rated AC 42V
Military Standard Not
Current Rating 500mA
Depth 9.4mm
Number of Functions 2
Packing Method TAPE AND REEL
Voltage - Rated DC 80V
Terminal Finish Matte Tin (Sn) - with Nickel (Ni) barrier
ECCN Code EAR99
Pbfree Code yes
JESD-609 Code e3
Tolerance 50%
Packaging Cut Tape
Physical
Material - Core Ferrite
Number of Pins 4
Package / Case SMD/SMT
Mounting Type SURFACE MOUNT
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 1 month ago)
