B82765C2A6
RoHS
/
Package /
Category Filters / Common Mode Chokes
Description
Copper (Cu) 4 FERRITE RoHS Compliant Common Mode Choke 25A 7mOhm 0.01MHz 1300muH
PDF
/
Inventory: 4068
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height 57.9882mm
Technical
Current Rating (Max) 25A
Number of Lines 4
Inductance-Nom (L) 1300 μH
DC Resistance (DCR) - Parallel 7mOhm
Inductor Type GENERAL PURPOSE INDUCTOR
Terminal Placement RADIAL
Inductor Application POWER INDUCTOR
Test Frequency 0.01MHz
Operating Temperature (Max) 125°C
Number of Functions 4
Shielding NO
Terminal Finish Copper (Cu)
ECCN Code EAR99
Pbfree Code yes
Tolerance 30%
Physical
Core Material FERRITE
Shape/Size Description RECTANGULAR PACKAGE
Terminal Shape FLEXIBLE LEAD
Mount Chassis Mount
