B82734R2322B030
RoHS
/
Package /
Category Filters / Common Mode Chokes
Description
Box RADIAL 2 INDUCTANCE IS MEASURED AT 0.1mA Common Mode Choke 3.2A 85mOhm 10kHz 32.5mm
PDF
/
Buying Options
Total Price: USD $2.88
Unit Price: USD $2.8776
≥1 USD $2.8776
≥10 USD $2.40328
≥100 USD $2.194368
≥500 USD $1.88078
≥1000 USD $1.724034
≥3000 USD $1.671824
Inventory: 709
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Dimensions
Width 32.5mm
Length 32.5mm
Height 31mm
Technical
Special Feature INDUCTANCE IS MEASURED AT 0.1 mA
DC Current 3.2A
Inductance-Nom (L) 6800 μH
Inductor Type GENERAL PURPOSE INDUCTOR
Lead/Base Style Pin
Terminal Placement RADIAL
Inductor Application POWER INDUCTOR
Max DC Current 3.2A
Test Frequency 10kHz
Inductance 6.8 mH
Operating Temperature (Max) 125°C
Voltage - Rated AC 250V
Construction Rectangular
Depth 21mm
Number of Functions 2
Shielding Unshielded
Packing Method Tray
Voltage - Rated DC 250V
Resistance 85mOhm
ECCN Code EAR99
Number of Terminations 4
Pbfree Code yes
JESD-609 Code e3
Tolerance 50%
Packaging Box
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Number of Pins 4
Terminal Shape FLAT
Mount Through Hole
Contact Plating Tin
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 2 months ago)
