B82734R2202B030
RoHS
/
Package /
Category Filters / Common Mode Chokes
Description
Box Tin (Sn) - with Nickel (Ni) barrier 2 INDUCTANCE IS MEASURED AT 0.1mA Common Mode Choke 2A 240mOhm 10kHz 32.5mm
PDF
/
Buying Options
Total Price: USD $2.27
Unit Price: USD $2.2704
≥1 USD $2.2704
≥10 USD $1.89552
≥100 USD $1.731136
≥500 USD $1.48368
≥1000 USD $1.451234
Inventory: 1135
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 21mm
Length 32.5mm
Height 31mm
Technical
Special Feature INDUCTANCE IS MEASURED AT 0.1 mA
DC Current 2A
Inductance-Nom (L) 20000 μH
DC Resistance (DCR) - Parallel 240mOhm
Inductor Type GENERAL PURPOSE INDUCTOR
Lead/Base Style Pin
Inductor Application POWER INDUCTOR
Max DC Current 2A
Test Frequency 10kHz
Inductance 20 mH
Lead Diameter 700 μm
Lead Pitch 15mm
Military Standard Not
Construction Rectangular
Depth 21mm
Number of Functions 2
Shielding Unshielded
Packing Method Tray
HTS Code 8504.50.80.00
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Terminal Finish Tin (Sn) - with Nickel (Ni) barrier
ECCN Code EAR99
Termination Radial
Number of Terminations 4
Pbfree Code yes
JESD-609 Code e3
Tolerance 50%
Packaging Box
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Terminal Shape FLAT
Mount Through Hole
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 2 months ago)
