B82733F2192B001
RoHS
/
Package Radial
Category Filters / Common Mode Chokes
Description
Radial Tin (Sn) - with Nickel (Ni) barrier 2 INDUCTANCE IS MEASURED AT 0.1mA Common Mode Choke 1.9A 279mOhm 10kHz 26.5mm
PDF
/
Buying Options
Total Price: USD $2.3
Unit Price: USD $2.2968
≥1 USD $2.2968
≥10 USD $1.95096
≥100 USD $1.798016
≥500 USD $1.60688
≥1000 USD $1.339034
≥3000 USD $1.300754
Inventory: 6165
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Dimensions
Width 24.8mm
Length 26.5mm
Height 14mm
Technical
Special Feature INDUCTANCE IS MEASURED AT 0.1 mA
DC Current 1.9A
Inductance-Nom (L) 15000 μH
Inductance Tolerance -50%
DC Resistance (DCR) - Parallel 279mOhm
Inductor Type GENERAL PURPOSE INDUCTOR
Terminal Placement DUAL IN-LINE
Inductor Application POWER INDUCTOR
Max DC Current 1.9A
Test Frequency 10kHz
Inductance 15 mH
Military Standard Not
Current Rating 1.9A
Construction Rectangular
Depth 24.8mm
Number of Functions 2
Shielding Unshielded
Packing Method Tray
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Terminal Finish Tin (Sn) - with Nickel (Ni) barrier
Resistance 279mOhm
ECCN Code EAR99
Number of Terminations 4
Pbfree Code yes
JESD-609 Code e3
Tolerance 30%
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Weight 10.000011g
Number of Pins 4
Terminal Shape FLAT
Package / Case Radial
Mount Through Hole
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 1 month ago)
