B82732R2222B030
RoHS
/
Package /
Category Filters / Common Mode Chokes
Description
Box Tin (Sn) 2 INDUCTANCE IS MEASURED AT 0.1mA Common Mode Choke 2.2A 110MOhm 10kHz 24mm
PDF
/
Buying Options
Total Price: USD $2.19
Unit Price: USD $2.1912
≥1 USD $2.1912
≥10 USD $1.83304
≥100 USD $1.673408
≥500 USD $1.4344
≥1000 USD $1.314834
≥3000 USD $1.27497
Inventory: 630
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 24mm
Length 24mm
Height 23mm
Technical
Special Feature INDUCTANCE IS MEASURED AT 0.1 mA
DC Current 2.2A
Inductance-Nom (L) 3300 μH
DC Resistance (DCR) - Parallel 110MOhm
Inductor Type GENERAL PURPOSE INDUCTOR
Lead/Base Style Pin
Terminal Placement DUAL IN-LINE
Inductor Application POWER INDUCTOR
Test Frequency 10kHz
Inductance 3.3 mH
Operating Temperature (Max) 125°C
Lead Pitch 12.5mm
Voltage - Rated AC 250V
Military Standard Not
Current Rating 2.2A
Construction Rectangular
Depth 16.5mm
Number of Functions 2
Shielding Unshielded
Packing Method Tray
Voltage - Rated DC 250V
Terminal Finish Tin (Sn)
Resistance 110mOhm
ECCN Code EAR99
Number of Terminations 4
Pbfree Code yes
JESD-609 Code e3
Tolerance 50%
Packaging Box
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Number of Pins 4
Terminal Shape FLAT
Mount Through Hole
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 2 months ago)
