B82731T2102A020
RoHS
/
Package /
Category Filters / Common Mode Chokes
Description
Tray Tin (Sn) - with Nickel (Ni) barrier 2 INDUCTANCE IS MEASURED AT 0.1mA Common Mode Choke 1A 630mOhm 10kHz 21.5mm
PDF
/
Buying Options
Total Price: USD $2.13
Unit Price: USD $2.1296
≥1 USD $2.1296
≥10 USD $1.8128
≥100 USD $1.670944
≥500 USD $1.493008
≥1000 USD $1.244232
≥3000 USD $1.208662
Inventory: 568
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 2 months ago)
Physical
Mount Radial
Terminal Shape FLAT
Number of Pins 4
Weight 14.999988g
Material - Core Ferrite
Shape/Size Description RECTANGULAR PACKAGE
Technical
Tolerance 50%
JESD-609 Code e3
Pbfree Code yes
Number of Terminations 4
ECCN Code EAR99
Resistance 630mOhm
Terminal Finish Tin (Sn) - with Nickel (Ni) barrier
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Packing Method Tray
Shielding NO
Number of Functions 2
Depth 13.5mm
Construction Rectangular
Current Rating 1A
Military Standard Not
Lead Pitch 10mm
Inductance 10 mH
Test Frequency 10kHz
Max DC Current 1A
Frequency - Self Resonant 10kHz
Inductor Application POWER INDUCTOR
Terminal Placement DUAL IN-LINE
Lead/Base Style Pin
Inductor Type GENERAL PURPOSE INDUCTOR
DC Resistance (DCR) - Parallel 630mOhm
Inductance Tolerance -30%
Inductance-Nom (L) 10000 μH
DC Current 1A
Special Feature INDUCTANCE IS MEASURED AT 0.1 mA
Dimensions
Height 21.1mm
Length 21.5mm
Width 13.5mm
Compliance
REACH SVHC No SVHC
RoHS Status RoHS Compliant
