B82731M2901A030

EPCOS
RoHS
/
Package /
Category Filters / Common Mode Chokes
Description Box Tin (Sn) - with Nickel (Ni) barrier 2 INDUCTANCE IS MEASURED AT 0.1mA Common Mode Choke 900mA 600mOhm 10kHz 21mm
PDF
/
Buying Options
Total Price: USD $2.23
Unit Price: USD $2.2264
≥1 USD $2.2264
≥10 USD $1.89464
≥100 USD $1.746272
≥500 USD $1.56068
≥1000 USD $1.300534
≥3000 USD $1.263337
Inventory: 1385
Minimum: 1
-
+

Technical Details

Supply Chain

Lifecycle Status PRODUCTION (Last Updated: 2 months ago)

Physical

Mount Radial
Terminal Shape FLAT
Number of Pins 4
Weight 8.000009g
Material - Core Ferrite
Shape/Size Description RECTANGULAR PACKAGE

Technical

Packaging Box
Tolerance 50%
JESD-609 Code e3
Pbfree Code yes
Number of Terminations 4
ECCN Code EAR99
Resistance 600mOhm
Terminal Finish Tin (Sn) - with Nickel (Ni) barrier
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Packing Method Tray
Shielding NO
Number of Functions 2
Depth 15mm
Construction Rectangular
Current Rating 900mA
Military Standard Not
Lead Pitch 12.5mm
Inductance 900 μH
Test Frequency 10kHz
Max DC Current 900mA
Frequency - Self Resonant 10kHz
Inductor Application POWER INDUCTOR
Lead/Base Style Pin
Inductor Type GENERAL PURPOSE INDUCTOR
DC Resistance (DCR) - Parallel 600mOhm
Inductance Tolerance -30%
Inductance-Nom (L) 15000 μH
DC Current 900mA
Special Feature INDUCTANCE IS MEASURED AT 0.1 mA

Dimensions

Height 20mm
Length 21mm
Width 10mm

Compliance

Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
