B82731M2801A030
RoHS
/
Package /
Category Filters / Common Mode Chokes
Description
Box Tin (Sn) - with Nickel (Ni) barrier 2 INDUCTANCE IS MEASURED AT 0.1mA Common Mode Choke 800mA 800mOhm 10kHz 21mm
PDF
/
Buying Options
Total Price: USD $2.23
Unit Price: USD $2.2264
≥1 USD $2.2264
≥10 USD $1.89464
≥100 USD $1.746272
≥500 USD $1.56068
≥1000 USD $1.300534
≥3000 USD $1.263337
Inventory: 1175
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 20mm
Length 21mm
Height 15.5mm
Technical
Special Feature INDUCTANCE IS MEASURED AT 0.1 mA
DC Current 800mA
Inductance-Nom (L) 22000 μH
DC Resistance (DCR) - Parallel 800mOhm
Inductor Type GENERAL PURPOSE INDUCTOR
Inductor Application POWER INDUCTOR
Frequency - Self Resonant 10kHz
Max DC Current 800mA
Test Frequency 10kHz
Inductance 22 mH
Lead Diameter 600 μm
Lead Pitch 12.5mm
Military Standard Not
Construction Rectangular
Depth 15mm
Number of Functions 2
Shielding Unshielded
Packing Method Tray
HTS Code 8504.50.80.00
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Terminal Finish Tin (Sn) - with Nickel (Ni) barrier
ECCN Code EAR99
Number of Terminations 4
Pbfree Code yes
JESD-609 Code e3
Tolerance 50%
Packaging Box
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Weight 8.000009g
Terminal Shape FLAT
Mount Radial
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 2 months ago)
