B82731M2351A030
RoHS
/
Package /
Category Filters / Common Mode Chokes
Description
Tray FLAT 4 INDUCTANCE IS MEASURED AT 0.1mA Common Mode Choke 350mA 4.5Ohm 10kHz 21mm
PDF
/
Buying Options
Total Price: USD $1.76
Unit Price: USD $1.76
≥1 USD $1.76
≥10 USD $1.49512
≥100 USD $1.377728
≥500 USD $1.23112
≥1000 USD $1.032134
Inventory: 1155
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 2 months ago)
Physical
Mount Radial
Terminal Shape FLAT
Number of Pins 4
Weight 8.000009g
Material - Core Ferrite
Shape/Size Description RECTANGULAR PACKAGE
Technical
Packaging Box
Tolerance 50%
JESD-609 Code e3
Pbfree Code yes
Number of Terminations 4
ECCN Code EAR99
Resistance 4.5Ohm
Terminal Finish Tin (Sn) - with Nickel (Ni) barrier
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Packing Method Tray
Shielding NO
Number of Functions 2
Depth 15mm
Construction Rectangular
Current Rating 350mA
Military Standard Not
Lead Pitch 12.5mm
Inductance 100 mH
Test Frequency 10kHz
Max DC Current 350mA
Frequency - Self Resonant 10kHz
Inductor Application POWER INDUCTOR
Lead/Base Style Pin
Inductor Type GENERAL PURPOSE INDUCTOR
DC Resistance (DCR) - Parallel 4.5Ohm
Inductance Tolerance -30%
Inductance-Nom (L) 100000 μH
DC Current 350mA
Special Feature INDUCTANCE IS MEASURED AT 0.1 mA
Dimensions
Height 20mm
Length 21mm
Width 10mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
