B82731H2701A30
RoHS
/
Package /
Category Filters / Common Mode Chokes
Description
Common Mode Chokes Dual 27mH 10kHz 700mA 1Ohm DCR Thru-Hole Box
PDF
/
Inventory: 6195
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 21.0058mm
Length 21.0058mm
Height 15.494mm
Technical
Current Rating (Max) 700mA
Number of Lines 2
DC Current 700mA
Inductance-Nom (L) 27000 μH
DC Resistance (DCR) - Parallel 1Ohm
Inductor Type GENERAL PURPOSE INDUCTOR
Terminal Placement DUAL IN-LINE
Inductor Application POWER INDUCTOR
Current 700mA
Test Frequency 10kHz
Inductance 27 mH
Approval Agency ENEC, UR, VDE
Voltage - Rated AC 250V
Military Standard Not
Depth 20mm
Number of Functions 1
Shielding NO
HTS Code 8504.50.80.00
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Terminal Finish Tin (Sn) - with Nickel (Ni) barrier
ECCN Code EAR99
Pbfree Code yes
JESD-609 Code e3
Tolerance 50%
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Terminal Shape SPECIAL
Mount Through Hole
