B82725J2802N020
RoHS
/
Package /
Category Filters / Common Mode Chokes
Description
Box Tin (Sn) 2 e3 Common Mode Choke 8A 20mOhm 10kHz 40.4mm
PDF
/
Buying Options
Total Price: USD $5.73
Unit Price: USD $5.7288
≥1 USD $5.7288
≥10 USD $4.63848
≥100 USD $4.123328
≥500 USD $3.89422
≥1000 USD $3.608
≥3000 USD $3.550721
Inventory: 672
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Length 40.4mm
Height 40mm
Technical
DC Current 8A
Inductance-Nom (L) 2700 μH
Inductance Tolerance 30%
DC Resistance (DCR) - Parallel 20mOhm
Inductor Type GENERAL PURPOSE INDUCTOR
Lead/Base Style Pin
Terminal Placement DUAL IN-LINE
Inductor Application POWER INDUCTOR
Max DC Current 8A
Test Frequency 10kHz
Inductance 2.7 mH
Lead Diameter 1 mm
Lead Pitch 12.5mm
Military Standard Not
Construction Rectangular
Depth 21.5mm
Number of Functions 2
Shielding NO
Packing Method Tray
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Terminal Finish Tin (Sn)
Resistance 20mOhm
ECCN Code EAR99
Number of Terminations 4
Pbfree Code yes
JESD-609 Code e3
Tolerance 30%
Packaging Box
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Number of Pins 4
Terminal Shape WIRE
Mount Radial
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 2 months ago)
