B82725J2103N022
RoHS
/
Package /
Category Filters / Common Mode Chokes
Description
Box Tin (Sn) 2 e3 Common Mode Choke 10A 13mOhm 10kHz 40.4mm
PDF
/
Buying Options
Total Price: USD $4.51
Unit Price: USD $4.5144
≥1 USD $4.5144
≥10 USD $3.65992
≥100 USD $3.252832
≥500 USD $3.18164
Inventory: 1109
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 2 months ago)
Physical
Mount Radial
Terminal Shape WIRE
Number of Pins 4
Material - Core Ferrite
Shape/Size Description RECTANGULAR PACKAGE
Technical
Packaging Box
Tolerance 30%
JESD-609 Code e3
Pbfree Code yes
Number of Terminations 4
ECCN Code EAR99
Resistance 13mOhm
Terminal Finish Tin (Sn)
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Packing Method Tray
Shielding NO
Number of Functions 2
Depth 21.5mm
Construction Rectangular
Current Rating 10A
Military Standard Not
Lead Pitch 12.5mm
Lead Diameter 1 mm
Inductance 1.8 mH
Test Frequency 10kHz
Max DC Current 10A
Inductor Application POWER INDUCTOR
Terminal Placement DUAL IN-LINE
Lead/Base Style Pin
Inductor Type GENERAL PURPOSE INDUCTOR
DC Resistance (DCR) - Parallel 13mOhm
Inductance Tolerance 30%
Inductance-Nom (L) 1800 μH
DC Current 10A
Dimensions
Height 40mm
Length 40.4mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
